[72] Multiphysics topology optimization for piezoelectric acoustic focuser
작성자 관리자
날짜 2023-12-26 14:35:30
조회수 74
G. H. Yoon, H. Choi, and S. HurComputer Methods in Applied Mechanics and Engineering 332 (2018): 600-623.
The application of piezoelectric materials allows many advantages such as reducing the number of parts and manufacturing cost of a mechanical system. Despite these merits, the performance predictions and optimization of piezoelectric-material-based devices are challenging because of the mutual coupling between electricity and mechanics. The analysis and the optimization become more challenging when acoustics are to be coupled with piezoelectric-material-based devices. In the present study, the mutual couplings among electric, mechanics, and acoustics are simulated and its applications for the topology optimization of an acoustic energy focuser are presented. Owing to the local optima issue, some blurred and unsuccessful layouts are obtained. To overcome this issue and impose the manufacturing constraint, a modified morphology density filter is also developed. With the presented approach, it is possible to determine some optimized piezoelectric rings to focus acoustic energy. Compared with the existing design methods, some better designs in terms of objective value can be obtained by the present approach.
